10m³Vertical industrial liquid co2 tank supplier

Thechnical Summary:

1. Can provide different code based on user requirement: GB/ ASME/CE certificate

2. Can be horizental or Vertical based on jobsite condition

3. Can special design based on stationary tank or movable tank or skid based on user funtion

4. Vacuum guarantee: 3 years

5. Complet equipment guarantee: one year

TAG: CNCD

Email us for quotes Chat on WhatsApp

Get Quotes

Products

If you have any suggestions or opinions about our products,please leave a message,and we will immediately answer your questions. thanks for your support.

Tel: +86-373-2677103
Fax: +86-373-2677103
WhatsApp: +86-17638186581
E-mail: jenny@cncdcontainer.com
Address: Fengquan Industrial Zone, Xinxiang city, Henan Province China

Related products
Description
Inquiry

Related products

Description

Product Description

Liquid carbon dioxide storage can be classified into polyurethane foaming insulation tank and vacuum powder adiabatic tank, with a designed working temperature of minus 40°.its main material can be 0Cr18Ni9 or 16MnDR.

This series of products , featuring a compact structure, can be applied in metallurgy, chemistry, food industry, and fire protection, etc. They are reliable, easy too perate and maintain Main technical parameter:

Main technical parameter:

1	Available max. volume	10m3
2	working pressure	2.16Mpa
3	Design temperature	-40°C
4	Design pressure	2.27Mpa
5	Total Volume	10.52 m3
6	Effective volume	10m3
7	Filling Ratio	0.95
8	Inner tank Material	16MnDR
9	Outside tank Material	Q245R
10	Diameter	2100mm
11	Length	7130mm
12	Empty weight	7000kg
13	Suitable	Lco2
14	Insulation method	vacuum powder or polyurethane insulation
15	Medium	Liquid carbon dioxide
