Position: Home > Products >Cryogenic Tank > 30m3 new Liquid carbon dioxide storage tank

30m3 new Liquid carbon dioxide storage tank

This liquid carbon dioxide storage tank includes vacuum powder insulation storage tank and polyurethane insulation storage tank.This vertical type tank is used to store carbon dioxide. The tank has many features such as long lifespan, compact structure, and less occupied area. We can also design products according to users' demands.

TAG: CNCD

Send a E-mail to us!

Get Quotes

Products

If you have any suggestions or opinions about our products,please leave a message,and we will immediately answer your questions. thanks for your support.

Tel: +86-373-2677103
Fax: +86-373-2677103
WhatsApp: +86-17050631847
E-mail: sale@cncdtank-china.com
Address: Fengquan Industrial Zone, Xinxiang city, Henan Province China

Related products
Description
Inquiry

Related products

Description

Thechnical Summary:

1. Can provide different code based on user requirement: GB/ ASME/CE certificate

2. Can be horizental or Vertical based on jobsite condition

3. Can special design based on stationary tank or movable tank or skid based on user funtion

4. Vacuum guarantee: 3 years

5. Complet equipment guarantee: one year

Product Description

Main technical parameter:

1	Available max. volume	30m3
2	working pressure	2.16Mpa
3	Design temperature	-40°C
4	Design pressure	2.27Mpa
5	Total Volume	31.6 m3
6	Effective volume	30 m3
7	Filling Ratio	0.95
8	Inner tank Material	16MnDR
9	Outside tank Material	Q245R
10	Diameter	2900mm
11	Length	8960mm
12	Empty weight	17440kg
13	Suitable	Lco2
14	Insulation method	vacuum powder or polyurethane insulation
15	Medium	Liquid carbon dioxide
