15000L best quality cryogenic tank Manufacturer

Thechnical Summary:

1. Can provide different code based on user requirement: GB/ ASME/CE certificate

2. Can be horizental or Vertical based on jobsite condition

3. Can special design based on stationary tank or movable tank or skid based on user funtion

4. Vacuum guarantee: 3 years

5. Complet equipment guarantee: one year

TAG: cryogenic tank Manufacturer CNCD

Email us for quotes Chat on WhatsApp

Get Quotes

Products

If you have any suggestions or opinions about our products,please leave a message,and we will immediately answer your questions. thanks for your support.

Tel: +86-373-2677103
Fax: +86-373-2677103
WhatsApp: +86-17638186581
E-mail: jenny@cncdcontainer.com
Address: Fengquan Industrial Zone, Xinxiang city, Henan Province China

Related products
Description
Inquiry

Related products

Description

Product Description

Xinxiang Chengde Energy Technology Equipment Co.,Ltd. is located at Xinxiang City, Henan province in 2002. It is a professional processing manufacture enterprise integrated with design, manufacture, installation and service.The company has gained national-level A2 pressure vessel manufacture license, D1/D2 pressure vessel design license, ISO9001 International Quality System Certificate, GC2/GC3 pressure piping design license, GC2/GC3 pressure piping installation license etc.Our main products are cryogenic liquid storage tank, large cryogenic liquid flat-bottomed storage tank, cryogenic liquid pump, air-bath vaporizer, water-bath vaporizer, gas pressure regulator, non-standard pressure vessel and so on.

Main technical parameter:

1	Available max. volume	15m3
2	working pressure	8bar,16bar or as customer requirement
3	Min Design temperature	-196°C
4	Max Design temperature	+50 °C
5	Total Volume	15.8m3
6	Effective volume	15m3
7	Filling Ratio	0.95
8	Inner tank Material	0Cr18Ni9
9	Outside tank Material	Q245R
10	Diameter	2600mm
11	Length	6150mm
12	Empty weight	8310kg
13	Suitable	LIN, LOX, LAr,LNG
14	Insulation method	vacuum powder or high vacuum multi-layer wrap insulation
15	Medium	liquid argon/ nature gas/ oxygen/nitrogen/ethylene
