1. Can provide different code based on user requirement: GB/ ASME/CE certificate
2. Can be horizental or Vertical based on jobsite condition
3. Can special design based on stationary tank or movable tank or skid based on user funtion
4. Vacuum guarantee: 3 years
5. Complet equipment guarantee: one year
Product Description
Our company owns well-established quality assurance system, complete processing equipment, advanced welding technology. Relying on the advantages of professionals and scientific management system, our company leads in this industry and has our products sold all over China as well as in the international market. With years of persistent endeavor, we have received countless favorable comments from our customers for the reliable, high-quality products and in-time after-sale service of our company.
Xinxiang Chengde Gas Equipment Co., Ltd. is a company full of vitality and prosperity. In terms of the future development, all the company staff firmly believe that the company will win a better future because they all regard quality as the basis, development as the way to success, market as the guidance and innovation as the power.
We extend the warmest welcome to all those who want to visit our company or want to start business and cooperation with us.
Main technical parameter:
1
Available max. volume
25m3
2
working pressure
8bar,16bar as customer requirement
3
Min Design temperature
-196°C
4
Max Design temperature
+50 °C
5
Total Volume
26.3m3
6
Effective volume
25m3
7
Filling Ratio
0.95
8
Inner tank Material
0Cr18Ni9
9
Outside tank Material
Q245R
10
Diameter
2600mm
11
Length
9150mm
12
Empty weight
~13500kg
13
Suitable
LIN, LOX, LAr,LNG
14
Insulation method
vacuum powder or high vacuum multi-layer wrap insulation
